Modified PET


         欄目：modified engineering plastics 發布時間：2021-05-31 08:28


        Environment-friendly flame-retardant, high mechanical strength and high temperature tolerance...
















				Modified PET







				Applications：Auto parts, home appliance parts, lamps and lanterns, and electric injection molding products (such as connector, relay, power switch, socket, coil framework) Modified Features: Reinforced, flame retardant/reinforced

				Product Features: Environment-friendly flame-retardant, high mechanical strength and high temperature tolerance









				測試項目與標準Test Items & Standards

				增強型號

				Reinforced

				阻燃/增強型號

				Flame Retardant/Reinforced





				項目Item

				測試標準Standard

				測試條件

				Test Condition

				國際單位

				S.I. Units

				PET-30GF

				FRPET-30GF





				機械性能 Mechanical Properties

				　





				拉伸強度Tensile Strength

				ASTM D638

				10mm/min

				MPa

				130

				120





				伸長率 Elongation

				ASTM D638

				10mm/min

				%

				2.5

				2.5





				彎曲強度 Flexural Strength

				ASTM D790

				2mm/min

				MPa

				180

				170





				彎曲模量Flexural Modulus

				ASTM D790

				2mm/min

				MPa

				7500

				8000





				懸臂梁缺口沖擊強度

				Impact Strength, Izod notched

				ASTM D256

				3.2mm,23℃

				J/m

				100

				90





				洛氏硬度 Rockwell Hardness

				ASTM D785

				R-Scale

				-

				120

				120





				熱性能 Thermal Properties

				　





				熱變形溫度

				Heat Distortion Temp

				ASTM D648

				0.45MPa,6.4mm

				℃

				230

				230





				1.8MPa,6.4mm

				220

				220





				電性能 Electrical Properties

				　





				體積電阻率Volume Resistivity

				ASTM D257

				-

				Ω.cm

				1016

				1016





				其他 Others

				　





				玻纖含量Glass Fiber

				--

				--

				%

				30

				30





				比重

				Specific Gravity

				ASTM D792

				23℃

				g/cm3

				1.54

				1.65





				收縮率Mold Shrinkage

				ASTM D955

				23℃

				%

				0.3/1.0

				0.3/0.9





				吸水率Weather Resistant

				ASTM D570

				23℃，24h

				%

				0.06

				0.06





				阻燃性Flammability

				UL94

				1.6mm

				class

				HB

				V0





				3.2mm

				HB

				V0





				建議加工工藝 Suggesting processing technology

				　





				熔體溫度Melt Temp

				　

				℃

				250-270

				250-270





				料筒溫度Barrel Zone Temp

				　

				℃

				235-275

				230-270





				模具溫度Mold Temp

				　

				℃

				80-110

				80-110





				預干燥Pre-Dry Requirements

				　

				　

				120-140℃

				4-6hr

				120-140℃

				4-6hr





				注：以上數值是根據實驗室標準測定的代表數值，

				僅供客戶參考，不作為質保承諾。

				　





				Note: The above data is based on standard laboratory condition,

				for reference only, not for product warranty.
